World-Class Performance in Similar Specifications Globally.
Equipped with an Advanced Power System, It Excels in Speed, Strength, Maneuverability, and Flexibility
Domestically Innovated Full-Sized General-Purpose Humanoid Robot Capable of Running.
It Features Stable Gait and Highly Flexible Movement, Enabling Autonomous Walking and Running on Complex Terrains and in Various Environments
360° Depth Perception. Equipped with 3D LiDAR and Depth Cameras
It Provides Real-Time High-Precision Spatial Data for Full Panoramic Scanning
1) Key dimensions: (1560+200) mm * 570mm * 220mm; (Body height 1.56 meters); The height of the head is 0.2 meters. The total height is about 1.76 meters; Body width: 0.57 meters; Body thickness: 0.22 meters)
2) Thigh length: 400mm; calf length: 400mm
3) Arm length: 338mm; Arm length: 338mm;
4) Single leg freedom: hip joint * 3+knee joint * 1+ankle joint * 1=5;
5) Single arm degree of freedom: 4;
6) Whole machine weight: approximately 47kg;
7) Joint unit ultimate torque: knee joint saves about 360N. m, hip joint saves 220N. m, ankle joint saves 45N. m, arm joint saves about 75N. m;
8) Walking speed: greater than 1.5m/s (potential mobility>5m/s);
9) Battery: Capacity 15Ah (0.864KWh), maximum voltage 67.2V;
10) Control and perception computing power: 2 * Intel Core i7-1265U;
11) Perception sensor configuration: 3D LiDAR+depth camera; 12) Standard dual battery configuration“
